[施乐] 施乐复印机装订器分页器Finisher C4,C5英文维修手册1.6版本

[复制链接]
发表于 2023-3-27 09:53:36 | 显示全部楼层 |阅读模式

注意:本帖含有图片和附件资料 登录 才可查看,没有帐号?

您需要 登录 才可以下载或查看,没有账号?立即注册

×
Finisher C4/C5
Service Manual Ver.1.6
施乐复印机装订器分页器Finisher C4,C5英文维修手册1.6版本

Issued with the introduction of the new Apeos C7070/C6570/C5570/C4570/C3570/C3070/C2570, ApeosPro C810/C750/C650 and Apeos C8180/C7580/C6580
Revision by adding information (Chapter 4 Adjustments, Chapter 6 Specifications, Chapter 9 Installation)
Revision of Chapter 9 by adding information

Issued with the introduction of the new Apeos 5570/4570

Revised due to WW suppor

Revised with the introduction of ApeosPrint C5570

Revised with the introduction of Apeos 7580/6580

011-101 MBX Vertical Sensor ON Jam (MBX M/C ONLY)
BSD-on: CH44.82
Description
The MBX Vertical Sensor did not turn ON within the specified time.
DC330 Codes for checking:
[013-192] MBX Vertical Sensor
[013-091] MBX Transport Motor
[013-081] MBX Gate Solenoid
Check the following Bin Solenoids when a jam occurs.
[013-082] 2Bin Gate Solenoid
[013-083] 3Bin Gate Solenoid
[013-084] 4Bin Gate Solenoid
[013-085] 5Bin Gate Solenoid
[013-086] 6Bin Gate Solenoid
[013-087] 7Bin Gate Solenoid
[013-088] 8Bin Gate Solenoid
[013-089] 9Bin Gate Solenoid
[013-090] 10Bin Gate Solenoid
Check Items
Clean the light emitter/light receptor of the MBX Vertical Sensor.
Check the feed section of the Roller for wear, dirt, or scratches.
Transport failure due to out-of-spec paper.
Remove any foreign matter in the feed section.
付费看帖
剩余高优质内容需要捐助 50.00 元 后可完整阅读下载
支持付费阅读,激励作者创作更好的作品。还请各位看官多多捐助啦!
