Caution
Many parts are secured by plastic tabs. Do not over flex or force these parts.
Do not over torque screws threaded into plastic.
Caution
Do not remove Red-colored screws. These screws secure key chassis components. Removal of Red-colored screws can result in chassis misalignment.
Caution
Cover the Imaging Units to avoid light exposure.
1. Wear an Electrostatic Discharge wrist strap.
2. Turn Off power and disconnect the power cord from the wall outlet and printer.
3. Disconnect all cables from the printer.
4. Remove these items:
• Imaging Units
• Transfer Belt
• Transfer Roller
• Trays
• Fuser
• Toner Cartridges
